    6000pcs/Hour Wood Pulp Paper Tray Forming Machine For 6 Worker

    Ask Lasest Price
    Brand Name : Wanyou
    Model Number : ZSJ-6000
    Certification : CE
    Price : negotiation
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 1 set per month
    Delivery Time : 95 working days
    • Product Details
    • Company Profile

    6000pcs/Hour Wood Pulp Paper Tray Forming Machine For 6 Worker

    Fully automatic egg tray forming machine


    Fully automatic recycling waste paper egg tray forming machine


    Egg Tray Machine (pulp molding machine) uses waste paper as raw material and produce different kinds of products according to your requirement,such as egg tray/dishes ,egg carto/box,fruit tray,industrial package tray,seeding tray ,win tray ,shoe support and small products packages ,etc. The different final products are decided by your market choice.


    Details of egg tray forming machine:


    Technical Parameters
    Egg Tray mould quantity48pcsContainer Required
    Raw materialWaste paper

    About 40ft*7

    (without dryer)

    Output for egg tray6000pcs/hour
    Net weight per piece (gram)70g-75g
    The volume of waste paper consumed450kg / hour
    The volume of water consumed1.35ton / hour

    The natural gas consumped of the dryer(about)


    180cbm/h


    Diesel Consumption
    Machine Weight5-20tons
    Egg tray Size295mm*295mm 30eggs

    Four parts of egg tray forming machine:


    NameFunction

    Pulping system


    Pulping system

    Including :

    mill pulp pump -1set

    water pump-2sets

    pulp pump -2sets

    pulping machine –1sets

    material of tank and disc:carbonized steel ,material of screen plate:stainless steel , pulping consistency:3-4%.


    Forming system


    Including

    48 moulds (6*8)forming machine -1set

    Vacuum pump-1set

    Compressor -2sets

    Washer –1set

    Vacuum tank-1pcs

    Air tank—1pcs

    Equipped with vacuum auto draining system;auto cleaning system for the forming mold and auto control cabinet.


    Drying system


    Including

    Drying oven –1set

    (L 40M*2.8M*H2.2M)

    Chain and tray –1sets

    Hot air pipe –1sets

    Chain wheel with shaft—1sets

    Drive motor –1set

    The temperature of each section can be adjusted independently;burners with French or Italian brand;


    The energy for option: LPG,GAS,diesel oil,Equipped with auto control cabinet.


    Stacking system


    Including

    Stacker-1set

    Height limit pressor-1set

    Used to stack the after-drying products.

    Machine Features of Paper Egg Tray Making Production Line :


    1). Controlled by automatic computer soft ware

    2). No need for installation, machine can start running only after connecting some pipes, power and water, and preparing the material

    3). Some parts are Germany brand or other famous brand

    4). Our egg tray machine can make different trays at same time by using different moulds

    5). Besides egg tray, fruit trays, our machine also can produce industrial package

    6). All installation and debugging work will be done before shipment.

    7). 20 years' experience on egg tray machine

    8). 2 years warranty time


    Company information:


    Jinan Wanyou Packing Machinery Factory is located in Jinan City, Shandong Province. We are a famous packing machinery factory which has a good integration of science, industry and trade. Our factory has been devoted to studying, developing and manufacturing packing machinery for many years, absorbing advanced technology and industrial art at home and abroad. Our factory has studied and developed ZSJ series paper pulp moulding plants, YS series paper carton automatic print fluting machines, BD series thin cutter paper slitter sand paper carton series cutter chains. These products are sold to many countries and regions, such as Argentina, Vietnam, Russia, Uzbekistan, Nigeria, Taiwan area and so on. Our factory insists on earnestly creating refined products and regards product quality as the life of our company. Today, with the rapid development of packing machinery, our factory desires to create refulgence with a great number of clients hand in hand.
