Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption

Jinan Wanyou Packing Machinery Factory
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption from wholesalers

    Buy cheap Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption from wholesalers
    • Buy cheap Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption from wholesalers
    • Buy cheap Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption from wholesalers
    • Buy cheap Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption from wholesalers
    • Buy cheap Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption from wholesalers

    Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption

    Ask Lasest Price
    Brand Name : Wanyou
    Model Number : RL- ZJM
    Certification : CE
    Price : negotiation
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 1 sets per month
    Delivery Time : 60 working days after get deposit payment
    • Product Details
    • Company Profile

    Paper Apple Tray / Egg Tray Manufacturing Unit With Low Energy Consumption


    Newly Made Paper Egg Tray Making Machine / Egg Tray Production Line / Pulp Molding Machine


    Newly Made Paper Egg Tray Making Machine / Egg Tray Production Line / Pulp Molding Machine uses waste paper as raw material to produce the egg trays for chicken farm factory or other customer who needs the trays. It has 2 types forming method: one is Reciprocating Type, the other is Rotary Type Egg Tray Making Machine. It can make many simple shape and large quantity demand egg trays, apple trays, egg cartons, egg boxes, wine trays, shoe trays, etc..using waste paper as raw material.


    Egg tray machine working flow as the following:


    1. Pulping system

    2. Forming system

    3. Drying system

    4. Packing System

    Packing system is choosable. It usually be used for Full Automatic Egg Tray Production Line.


    The machine Features:


    1. controlled by computer, no needs any construction.

    ​ 2. We could make all kinds of moulds for you, and it's very easy to change any moulds to the machine.

    ​ 3. England technology, and​ spare parts is very famous brand from Germany, Taiwan...

    ​ 4. with 2 years warranty.

    ​ 5. The installation of the whole line is easy.

    All the machine is in computer control, which is also very easy to operate and donnot need high level knowledge requirement for the workers.

    Our Paper Egg Tray Machine saves production cost, and saves space. it is quitely used by small medium enterprises.

    Our machine can turn your waste paper and books into Money!


    Quick Detail

    Condition: New

    Product Type: Egg Tray Machine

    Processing Type: Pulp Molding Machine

    Place of Origin: Shandong, China (Mainland)

    Brand Name: RUNLIANG

    Voltage: 220-440V

    Power(W): Different Machine Model

    Dimension(L*W*H): 7m*2.2m*2.2m

    Weight: 8 tons-15tons

    Certification: CE & ISO

    Warranty: 2 years

    After-sales Service Provided: Engineers available to service machinery overseas

    Capacity: 350pcs/h-5000pcs/h

    Color: As customer needs

    Frequency: 50Hz-60Hz

    Application: egg tray,fruit tray,bottle tray

    Workshop required: 150-600㎡

    Worker required: 5-6 persons

    Fuel: Coal, Natural Gas, Disel, LPG and so on

    Automation: Automatic and fully automatic

    Keyword: Egg tray machine


    This production line is suitable for the following products:

    Egg tray(30-egg) Egg box/egg carton(6-egg, 10-egg, 12-egg, 6+6-egg, 15-egg, 18-egg and etc)

    Fruit tray (for apple,tomato, pear and etc) Cup carrier(4 pack and 2 pack) Seeding tray and bottle trays.

    Some medical-care products and fixed shape(the design doesn't change frequently) pulp molding products with large quantity.


    Technical data


    1Molds quantity40pcs+5pcs(5*8)60pcs+5pcs(5*12)32pcs+4pcs(4*8)18pcs+3pcs(3*6)12pcs+3pcs(3*4)
    2Raw materialWaste paperWaste paperWaste paperWaste paperWaste paper
    3capacity4000-4500pcs/h5000pcs/h3000pcs/h2400pcs/h1800pcs/h
    4Weight of tray70g-75g70g-75g70g-75g70g-75g70g-75g
    5Waste paper consumption500kg/h water can be650kg/h225kg/h180kg/h135kg/h
    6Water consumption1-1.5t/h1.5-2 t / hour water c0.6T/h0.5T/h036T/h
    7natural gas consumption60 m³/h75-80 m³/h30m³25m³20m³
    8Workshop dimensionWithout dryerMore than200M²

    More than300M²


    120M²100M²100M²
    With dryer500M²(10*50 M)

    750M²(15*50 M

    )

    55*12M8*35M8*35M
    9Installed powerWithout dryer190KW

    240KW


    60KW55KW45KW
    With dryer220KW290KW100KW90KW80KW
    10Machine dimensionWithout dryer13*4m19*10m4*10M4*10M4*10M
    With dryer40*4m50*10m4*354*32M4*30
    11Dimension containerWithout dryer40ft*240ft*340ft*240ft*240ft*2
    With dryer40ft*340ft*440ft*540ft*440ft*4

    Payment and delivery


    Trade termsFOB Qingdao or EXW Factory
    Delivery timeAbout 35 working days after receiving the deposit.
    Payment termBY T/T 30%DEPOSIT+70%BALANCE or 30% TT Deposit + 70% LC
    Time of paymentWhen the deposit is paid, the machine will begin to be produced. And the balance should be paid by the consignee (the buyer) before the delivery.
    Warranty timeTwo years after the Egg tray machine received.
    TERMS OF DELIVERYFOB Qingdao Port, China
    PackageIn container
    CertificationCE

    Factory Introduction

    Jinan Runliang Packing Machinery Co.,Ltd is a famous packing machinery company which has a good mix of science, industry and trade.

    It has been devoting to studying, developing, and manufacturing of packing machinery for more than ten years.

    It absorbs advanced technology and industrial arts at home and abroad, and has studied and developed ZSJ series paper pulp molding plant, YS series paper carton automatic print fluting machine, BD series thin cutter paper slitter and paper carton series cutter chain.

    These products are sold to many countries and areas, such as Algeria, Tunisia, Argentina, Vietnam, Russia, Uzbekistan, Nigeria, Taiwan and so on.


    Don’t miss the chance of promoting the production efficiency of your company.


    Welcome to contact us.


    FAQ


    (1). What kind of material we can use as the raw material?


    Any kind of waste paper like old newspaper,magazines,books,A4 paper, corrugated cartons, paperboard etc.


    (2). What kind of Fuel can be used for the whole production line?


    Coal, natural gas, and dieseal oil.


    (3). What kind of products can be made by this machine?


    All paperpackage such as paper egg tray, egg carton,egg box, fruit tray, bottle tray, cup tray, consumer product package, medical disposable container etc.


    (4). Are you a manufacturer or a trading company?


    Yes, our company has been fabricating pulp molding machine since 2000. We are one of the


    most important pulp molding machine maufacturers in the world, and we are famous pulp


    molding machine manufacturer in China, providing high quality and production capacity pulp molding

    machinery at reasonable prices to the world.

    (5). What capacity egg tray machine can you supply?

    At the moment, we can supply 350 pcs/h, 700, 1000, 1300, 1800, 2000, 2400, 3000pcs/h capcaity egg tray machine.


    Transfer Belt for dryer system
